ELECTRON PM700

Powered Compact 15 Inch LF + 1 Inch HF  2 Way Full-Range Loudspeaker



Features

  • Powered two-way, mid-high line array module
  • Two channel amplifier 700 W LF + 100 W HF Class D
  • Italian (B&C) 1 inch exit pure titanium HF compression driver
  • Italian (B&C) 15 inch LF transducer with weather protected cone and plates for outdoor use
  • Unique rotatable 60° x 40° constant-directivity horn
  • Ultra-compact low profile 5-side multipurpose design with monitor slant
  • Integral M8 threaded points for suspension (optional)
  • Vented LF enclosure, Solid bass down to 55Hz



Category:

The ELECTRON PM700 compact powered loudspeaker system joins the Lloyd lee Co. family of professional sound touring products. The two-way amplifier design of the ELECTRON PM700 sets a new industry benchmark in audio performance, efficiency and power density. The 700 W amplifier provides extended bandwidth, improved dynamic range and exceptionally low distortion. Signal processing is accomplished by way of a powerful 24 bit DSP providing unparalleled control over critical signal parameters.



The PM700 is an ultra-compact, low profile loudspeaker designed for main system or stage monitor applications. PM700 employs a long excursion Italian (B&C) 15 inch woofer that delivers rock-solid bass response and excellent midrange clarity with exceptional reliability. A specially designed crossover network integrates the speaker with an Eighteen Sound 1 inch pure titanium HF compression driver. The driver is coupled to a unique 60° x 40° constant directivity horn that is rotatable for precise and even coverage depending on application. HF overload protection is provided for reliable, long term operation.



The PM700 is designed for medium-throw applications, monitors or drum fills and can be combined with the PS1000 for breath-taking full-range sound. The PM700 is an ideal solution for events like conferences, parties, club sound, installations of individual speakers or clusters in entertainment, cultural or religious venues, as well as on stage with bands as stage monitors.



Applications

  • Live Sound
  • Auditorium
  • Houses of Worship
  • Club sound
  • Various Installations

Technical Specification



TYPE Powered Two-way compact/monitor (full-range)
FREQUENCY RANGE 41Hz-19kHz
DRIVERS    LF 1  x 15inch reflex-loaded direct radiator
                    HF 1 x 1 inch exit HF compression driver horn loaded
Nominal HF Amplifier Power



Nominal LF Amplifier Power

100W



700W

MAXIMIUM SPL (CALCULATED @ IM) 124dB continuous, 130dB peak
DISPERSION (-6db)

Rotatable Horn

60º horizontal x 40º vertical

YES

ENCLOSURE Trapezoid , BWP ply construction
FINISH Lloyd Lee Co. weather resistant textured paint cover
PROTECTIVE GRILLE Perforated Steel Powder Coated, 16G .
AC Requirements 240 V, 50 Hz/60 Hz
CONNECTORS Input: Female XLR

Loop Thru: Male XLR

AC Input: powerCON

AC Output: powerCON

DIMENSIONS — mm x — mm x — mm  ( W x H x D)
WEIGHT — kg
