ENCORE SERIES EM25

High Output Dual 15 inch LF + 1.4 Inch HF 2 Way Full-range Loudspeaker



Feature

  • Two-Way High-Output Full-range
  • 215HP 1400W continuous, 5600W peak power handling
  • 1.4 inch exit B&C compression driver for high power and Precise vocal reproduction
  • 2 x 15 inch B&C LMF transducer with weather protected cone and plates for outdoor use
  • Advanced crossover with HF protection
  • Vented LF enclosure, Solid bass down to 35Hz



Category:

The EM25 is a dual 15 inch Full-range speaker system that employ two very high-power B&C 15 inch woofers which deliver excellent mid-range clarity and low frequencies with exceptional reliability. A specially designed crossover network integrates the 15 inch speakers to a high power 1.4 inch large format driver. The driver is coupled to a unique elliptical 70° x 50° Constant-directivity horn for smooth and even coverage. HF overload protection is provided for reliable, long term operation. The 50° coverage angle of the EM25 is wide enough to provide coverage of an audience when used one-per side yet narrow enough to allow splaying of multiple enclosures without excessive coverage overlap.



The EM25 is designed for medium-throw PA applications, side fills or drum fills, It excels where all other dual 15 inch loudspeakers fall short on-power and detail. The EM25 are an excellent choice when the application calls for high performance and simplicity. A pair of EM25 and a single, high-power amplifier is a complete sound system capable of reinforcing bass and kick drum or playing high-level music in clubs and other venues. The EM25 can be combined with ES28 subwoofer for incredible full range sound.

Applications

  • Live Sound
  • Auditorium
  • Houses of Worship
  • Club sound
  • Various Installations

Technical Specification

TYPETwo-way compact  (full-range)
FREQUENCY RANGE39Hz-19kHz
DRIVERS    LF2  x 15inch reflex-loaded direct radiator
                      HF1 x 1.4 inch exit HF compression driver horn loaded
RATED POWER1400W AES, 5800W peak
SENSITIVITY101dB
MAXIMIUM SPL (CALCULATED @ IM)130 dB continuous, 136dB peak
NOMINAL IMPEDANCE4 ohms
DISPERSION (-6db)

Rotatable Horn

70º horizontal x 50º vertical

CROSSOVER1.5kHz passive
ENCLOSURETrapezoid , BWP ply construction
FINISHLloyd Lee Co. weather resistant textured paint cover
PROTECTIVE GRILLEPerforated Steel Powder Coated, 16G .
CONNECTORS2 x Neutrik NL4
DIMENSIONS485 mm x 1195 mm x 405 mm  ( W x H x D)
WEIGHT— Kg
